www.agneovo.com

The AG Neovo QX2702 is a 27-inch 4K display purpose-built for environments where precision, control, and uptime are paramount. With

4× HDMI inputs along with native quad-view capabilities, it allows operators to monitor up to four video sources simultaneously in flexible

layouts, eliminating the need for external switchers. The display supports remote management via LAN and RS232 loop-through, enabling

seamless integration into control room systems. Combined with blackout mode for low-light conditions, industrial-grade durability, and

optional custom keypad shortcuts, the display empowers system integrators to simplify installations while ensuring long-term operational

stability.

QX2702 27-INCH 4K DISPLAY WITH MULTIPLE INPUTS

FEATURES

• 4× HDMI with Quad-View: Displays four independent sources on a

single screen, enabling eicient multi-source monitoring without external

multiviewer hardware.

• DisplayPort Daisy-Chain: Mirrors the selected input to a second display,

allowing simple signal extension without additional splitters.

• LAN Control and RS-232 Loop-Through: Enables centralised

configuration and daisy-chain control across multiple displays from one

control point.

• External Keypad Support: Works with optional keypads to provide fast

access to preset functions for improved operational eiciency.

• Dimming Knob Compatibility: Supports an external dimming knob for

precise, tactile brightness adjustment during critical monitoring tasks.

• Blackout Mode: Instantly blanks the screen through the external keypad,

helping operators eliminate light spill in dark-room environments.

• Ultra-Low 2 Nits: Achieves extremely low brightness while maintaining

visibility, reducing eye fatigue during overnight surveillance.

• Robust Design for 24/7 Operation: NeoV™ Optical Glass, Anti-Burn-In™

technology, and a reinforced metal chassis ensure long-term durability in

demanding control-room conditions.

• Neovo Controller: Oers unified software-based management across

multiple displays, simplifying setup, monitoring, and batch configuration.

TECHNICAL DRAWING

1.01

SPECIFCATIONS SUBJECT TO CHANGE WITHOUT NOTICE.

www.agneovo.com

THIS DRAWING ON THIS PRINTAND INFORMATION BELONG WITH AG Neovo.

ANY REPRODUCTION IN PART OR WHOLE WITHOUT WRITTEN PERMISSION

OF AG Neovo IS PROBITIED.

THIRD ANGLE

PROJECTION

V.

SCALE

1:1

UNITS

mm

QX2702

596.736(ACTIVE AREA)

627.6(OPEN AREA)

653.2

(OUT LINE )

335.7(ACTIVE AREA)

366.4(OPEN AREA)

392.0

(OUT LINE )

12.8

12.8

12.8

12.8

20.6

57.0

4-M4

100.0

100.0

276.6276.6

157.5134.5
