PCIE-1158 Startup Manual 1

Before you begin installing your card, please make sure that

the following items have been shipped:

•1 x PCIE-1158 8-port PCIe USB Vision Frame Grabber

If any of these items are missing or damaged, please con-

tact your distributor or sales representative immediately.

General

•Chipset:

-4RenesasμPD720202USB3.0hostcontroller

-CompliantwithUSB3.0SpecicationRevision1.0

- Compliant with Intel

®

xHCISpecicationRevision1.0

•Interface:PCIe2.04x

•DataTransferRate:

-SuperSpeed

- High Speed

- Full Speed

- Low Speed

•CurrentProtection:900mAper-portcurrentlimit

Note: For better compatibility, please change the

PCIesettingstoGen2.0ondevicecardslot.

MechanicalandEnvironmental

•Dimensions(LxW):153x106mm

•PowerRequirements:Slot:PCIe2.0standard

•NetWeight:300g

PCIE-1158 8-port PCI Express USB Vision Frame Grabber

Startup Manual

MainBoardConnectors

LabelFunction

USB1~USB8USB3.0Ports1~8

Connector1

AT/ATX12V

DC

input 4-pin power con-

nector

AT/ATX12VDCInput4-pinPowerConnector

PinFunction

Pin 1GND

Pin2GND

Pin3+12V

Pin 4+12V

Figure 1: AT/ATX 12V DC Input 4-pin Power Connector

Figure 2: Slide Switches

ConnectorsPackingList

FormoreinformationonthisandotherAdvantech

products, please visit our website at:

http://www.advantech.com

For technical support and service, please visit our

support website at:

http://support.advantech.com.tw/support/default.

aspx

ThismanualisforthePCIE-1158SeriesRev.A1

PartNo.2041115800

Printed in China

1st Edition

October2021

Specications

Switch(Reserved)
