PCE-5B18-0GA1 (PCE-7B19-0GA1) Startup Manual 1
Before you begin installing your card, please make sure that
the following items have been shipped:
• 1 x 2-port USB Cable p/n: 1700002204
• PCE-5B18-0GA1 (PCE-7B19-0GA1)
• Startup Manual p/n: 20417B1900
• M4*6*0.7 Round Screws (15pcs) p/n: 1939000410
• 2 Year Quality Warranty Card p/n: 2190000902
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
PCE-5B18-0GA1 (PCE-7B19-0GA1) Backplane: 19
(18)-slot BP for 20-slot Chassis, 1 x PICMIG 1.3,
2 x (1) PCIe, 16 x 32-bit/64-bit PCI
Startup Manual
Standard Functions
• PICMIG 1.3 slots:
PCE-7B19-0G supports PCE-7xxx CPU boards
PCE-5B18-0G supports PCE-5xxx CPU boards
• PCIe slots:
PCE-7B19-0G supports two PCIe p1-x8 slots
PCE-5B18-0G supports one PCIe x16 slot
• 32-bit PCI slots:
Sixteen 32 bit/33 MHz, 64 bit/66MHz PCI slots
Bridge Chip: Diodes PI7C9X113SLFDE
• USB (2.0) ports:
Four Universal Serial Bus ports as pin headers
Mechanical and Environmental
• Dimensions: 327.66 x 417 mm
• Power supply voltage: +12 V, +5 V, -12 V, -5 V,
+3.3 V, +5 VSBY
• Power requirements: Refer to the CPU board, add-
on card & peripherals
• Operating temperature: 0 ~ 60°C
• Weight: 1.7 kg (weight of board)
Specications Packing List
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://support.advantech.com/
This manual is for the PCE-5B18-0GA1 (PCE-7B19-
0GA1) series.
Part No. 20417B1900
Printed in China
1st Edition
January 2025
2 PCE-5B18-0GA1 (PCE-7B19-0GA1) Startup Manual
The backplane has a number of connectors and jump-
ersthatallowyoutocongureyoursystemtosuityour
application. The table below lists the function of each of
the jumpers and connectors:
Connectors
Part Reference Function
SHBA1 ~ SHBD1 PICMG 1.3 CPU board slot
PPCIE1
PCE-7B19-0G: PCIe p2-x8 slot
PCE-5B18-0G: Not available
PPCIE2
PCE-7B19-0G: PCIe p2-x8 slot
PCE-5B18-0G: PCIe x16 slot
PPCI1 ~ PPCI4 33MHz (32bit) PCI bus slot
P1PCI1 ~ P1PCI2
33MHz (32bit)/66MHz (64bit) PCI
bus slot (Secondary 1)
P2PCI1 ~ P2PCI3
33MHz (32bit)/66MHz (64bit) PCI
bus slot (Secondary 2)
P3PCI1 ~ P3PCI3
33MHz (32bit)/66MHz (64bit) PCI
bus slot (Secondary 3)
P4PCI1 ~ P4PCI4
33MHz (32bit)/66MHz (64bit) PCI
bus slot (Secondary 4)
EATXPWR1 ATX 2.0 power connector 24 pin
EATPWR1 AT 12-pin power connector
ATX12V1
ATX 12 V auxiliary 4-pin power
connector
ATX12V2
ATX 12 V auxiliary 4-pin power
connector
EATX12V1
ATX 12 V auxiliary 8-pin power
connector
PWR3V1 3.3 V auxiliary power connector
PWR3V2 3.3 V auxiliary power connector
PWR5V1 5 V auxiliary power connector
PWR5V2 5 V auxiliary power connector
VOLT1 Alarm board/CMM power connector
FAN1 ~ FAN7 Fan connectors
FANDEC1 Fan speed detector connector
SMBUS1 ~ SMBUS3
Chassis sensor board connectors
JFP1 Power and reset button connector
USB12 Two USB port pin header
USB34 Two USB port pin header
PSON2
5VSB and PSON connector for
AT power supply
Jumpers
Part Reference Function
PSON1 ATX/AT mode selection
Jumper Settings
PSON1: ATX AT Mode Selection
Jumper Setting Function
AT Mode
ATX Mode (Default)
ConnectorPinDenitions
EATXPWR1
Pin Name
1 3.3 V
2 3.3 V
3 GND
4 5 V
5 GND
6 5 V
7 GND
8 PWROK
9 5VSBY
10 12 V
11 12 V
12 3.3 V
13 3.3 V
14 -12 V
15 GND
16 PSON#
17 GND
18 GND
19 GND
20 -5 V
21 5 V
22 5 V
23 5 V
24 GND
123
123
Connectors and Jumpers Connectors and Jumpers (Cont.)
PCE-5B18-0GA1 (PCE-7B19-0GA1) Startup Manual 3
PWR5V1 ~ PWR5V2
Pin Name
1 5 V
2 5 V
3 5 V
4 GND
5 GND
6 GND
VOLT1
Pin Name
1 5VSBY
2 GND
3 GND
4 -5 V
5 5 V
6 3.3 V
7 -12 V
8 12 V
FAN1~ FAN7
Pin Name
1 GND
2 12 V
3 FANIO1 ~ FANIO7
FANDEC1
Pin Name
1 FANIO1
2 FANIO2
3 FANIO3
4 FANIO4
5 FANIO5
6 FANIO6
7 FANIO7
SMBUS1~ SMBUS3
Pin Name
1 5 V
2 C-SMBCLK
3 C-SMBDAT
4 GND
EATPWR1
Pin Name
1 PWROK
2 5 V
3 12 V
4 -12 V
5 GND
6 GND
7 GND
8 GND
9 -5 V
10 5 V
11 5 V
12 5 V
ATX12V1 ~ ATX12V2
Pin Name
1 GND
2 GND
3 12 V
4 12 V
EATX12V1
Pin Name
1 GND
2 GND
3 GND
4 GND
5 12 V
6 12 V
7 12 V
8 12 V
PWR3V1~ PWR3V2
Pin Name
1 3.3 V
2 3.3 V
3 3.3 V
4 GND
5 GND
6 GND
Connectors and Jumpers (Cont.) Connectors and Jumpers (Cont.)
