PCE-5B13(7B14)-03 Startup Manual 1
Before you begin installing your card, please make sure
that the following materials have been shipped:
• One 2 port USB able P/N: 1700002204
• PCE-5B13(7B14)-03 startup manual
• M4*6*0.7 round screws (20 pieces) P/N: 1939000410
• 2-year quality warranty card P/N: 2190000902
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
PCE-5B13(7B14)-03 Backplane: 13(14)-slot BP for 14-Slot
Chassis, 1 x PICMIG 1.3, 9 (10) x PCIe, 3 x 32-bit/33-MHz
PCI
Standard functions
• PICMG 1.3 Slot:
PCE-5B13-03 supports PCE-5xxx CPU Cards
PCE-7B14-03 supports PCE-7xxx CPU Cards
• PCIe Slots:
PCE-5B13-03: 1 x PCIe x16, 8 x PCIe x4
PCE-7B14-03: 2 x PCIe x8, 3 x PCIe x4
• 32-bit PCI Slots:
PCE-5B13-03: 3 32-bit/33-MHz PCI
PCE-7B14-03: 3 32-bit/33-MHz PCI
• USB (2.0) Support: Four Universal Serial Bus ports to
Backplane
Note: Some add-on cards installed on this backplane
may cause CPU card BIOS resource allocation
problems, if this occurs please contact Advan-
tech technical support staff for help in solving the
problems.
Mechanical and Environment
• Dimensions: 327.66 x 315.45 mm
• Power supply voltage: +12 V, +5 V, -12 V, -5 V, +5 V
SBY, +3.3 V
• Power requirements: Depends on the CPU board, add-
on card & peripherals
• Operating temperature: 0 ~ 60° C
Specications
Packing List
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://www.advantech.com/support
This manual is for the PCE-5B13-03A1E(PCE-7B14-
03A1E) series.
Part No. 20015B1300
Pr i n t e d i n C h i n a
1st Edition,
Jan. 2018
2 PCE-5B13(7B14)-03 Startup Manual
Connectors and Jumpers
This table shows the function of each jumper and connector:
Connectors
Label Function
SHBA1~SHBD1
PICMG1.3 CPU board slot
PPCIE2
PCIe x 16 slot (Only on PCE-
5B12-07)
PPCIE1, PPCIE2
PCIe p2-x8 slots (Only on PCE-
7B13-07)
P1PCIE1~P1PCIE3
PCIe p2-x4 slots
PPCI1~ PPCI3 32 Bit / 33 MHz PCI Bus slots
EATXPWR1
ATX2.0 24-pin Power Connector
EATX12V1
ATX 12V Auxiliary 8-pin Power
Connector
ATX12V1
ATX 12V 4-pin Power Connector
PWR3V1 3.3V Auxiliary Power Connector
PWR3V2
3.3V Auxiliary Power Connector
VOLT1
Alarm board / CMM Power Con-
nector
FAN1~5
FAN Connector (Horizontal Type)
FAN6~7 FAN Connector (Vertical Type)
FANDEC1
FAN speed detector Connector
(Optional)
SMBUS1~SMBUS2
System Management Bus
(Optional)
JFP1
Power and Reset button Con-
nector
IPMB1 IPMB Connector (Optional)
USB12
Two USB port pin header
USB34 Two USB port pin header
Note: In this backplane’s default conguration, FAN-
DEC1, SMBUS1~SMBUS3, IPMB1 pin-headers
are NOT populated, those footprints are reserved
for customization.
Jumpers
Label Function
PSON1
ATX / AT Mode Selection
EATXPWER1
Pin Name
1
3.3 V
2 3.3 V
3
GND
4 5 V
5
GND
6
5 V
7
GND
8 Power OK
9
5 V SBY
10
12 V
11
12 V
12 3.3 V
13
3.3 V
14 -12 V
15
GND
16 PSON#
17
GND
18 GND
19
GND
20 -5 V
21
-5 V
22 5 V
23
5 V
24 GND
ATX12V1
Pin Name
1
GND
2 GND
3
12 V
4 12 V
Connectors and Jumpers (Cont.)
