PCE-5B12-00 Startup Manual 1

Before you begin installing your card, please make sure that

the following items have been shipped:

•PCE-5B12-00A1E startup manual 1st ED

•M4*6*0.7 Round Screws P/N: 1939000410

•2-year Quality Warranty Card P/N: 2190000902

If any of these items are missing or damaged, please con-

tact your distributor or sales representative immediately.

Standard Functions

•PICMG 1.3 slots: PCE-5B12-00A1Esupports PCE-5000

and 7000 series CPU boards

•PCIe slots: 10 PCIe x16 and 1 PCIe p1-x4

*If you have any questions about memory, I/O or IRQ

resource limitations, please contact Advantech locally or

FAE for further support.

•PCIe switch: One 5 ports/48 lanes and two 24 ports/96

lane PCIe Gen2 switch reduce data latency

•USB (2.0) ports: 4 Universal Serial Bus ports as pin

headers

Mechanical and Environment

•Dimensions: 327.66 x 417 mm

•Power supply voltage: +12 V, +5 V, -12 V, -5 V, +3.3 V,

5 VSB

•Power requirements: Refer to CPU board, add-on card

& peripheral documentation

•Operating temperature: 0 ~ 60° C (Depending on sys-

tem thermal solution)

•Weight: 1.1 kg (weight of board)

PCE-5B12-00A1E Backplane: 12-slot BP for 20-slot

chassis, 10 PCIe x16, and 1 PCIe x4

Startup Manual

The backplane has a number of connectors and jumpers

that allow you to configure your system to suit your ap-

plication. The table below lists the function of each of the

connectors and jumpers.

Connectors

Part ReferenceFunction

SHBA1 ~ SHBD1PICMG 1.3 CPU board slot

PPCIEX4_1PCIe p1-x4 with PCIe x16 slot

P1PCIEX16_1~5PCIe x16 slot

P2PCIEX16_1~5PCIe x16 slot

EATXPWR1ATX 2.0 24-pin power connector

EATPWR1AT 12-pin Power connector

ATX12V1

ATX 12 V Auxiliary 4-pin power

connector

ATX12V2

ATX 12 V Auxiliary 4-pin power

connector

EATX12V1ATX 12 V 8-pin power connector

EATX12V2ATX 12 V 8-pin power connector

PWR3V13.3 V Auxiliary power connector

PWR3V23.3 V Auxiliary power connector

PWR_4P1

ATX 5V & 12V 4-pin power con-

nector

VOLT1Alarm board

FAN1 ~ FAN7Fan connectors

FANDEC1Fan speed detect connector

SMBUS1 ~

SMBUS2

Chassis sensor board connectors

JFP1Power and reset button connector

IPMB1IPMB connector

USB12USB connector

USB34USB connector

PSON2

ATX feature Connector (5 VSB,

PSON) for Advantech redundant

power supply: 1757001757,

1757001760, 1757001758,

1757001761, 1757001759,

1757001677

Connectors and Jumpers Packing List

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

http://www.advantech.com/eplatform

For technical support and service, please visit our

support website at:

http://www.advantech.com/support/

This manual is for PCE-5B12-00A1E.

Part No. 20065B1200

Printed in China

Edition 1,

May 2013
