PCE-5B10-04A1E Startup Manual 1
Before you begin installing your card, please make sure
that the following materials have been shipped:
• 2 Two Port USB Cable P/N: 1700002204
• PCE-5B10-04A1E Start-up Manual
• M4*6*0.7 Round Screws (20 pieces) P/N: 1939000410
• 2 years quality warranty card P/N: 2190000902
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
PCE-5B10-04A1E Backplane: 10-slot BP for 14-Slot
Chassis, 1 PICMIG 1.3, 5 PCIe, 4 32-bit/33-MHz PCI
Startup Manual
Standard PC functions
PICMG 1.3 Slot:
PCE-5B10-04A1E supports PCE-5XXX CPU Cards
PCIe Slots:
1 PCI-E x 16 Slot
4 PCI-E x 1 Slots
32-bit PCI Slots:
4 32-Bit / 33-MHz PCI Slots
USB (2.0) support: Four Universal Serial Bus ports to
Backplane
Mechanical and Environment
Dimensions: 327.66 x 315.45 mm
Power supply voltage: +12 V, +5 V, -12 V, -5 V, +5 V
SBY, +3.3 V
Power requirements: Depends on the CPU Board, ad-
don Card & Peripherals
Operating temperature: 0 ~ 60° C
•
•
•
•
•
•
•
•
Specications
Packing List
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://www.advantech.com/support
This manual is for the PCE-5B10-04A1E series Rev.
A1
Part No. 200K5B1000
Printed in China
1st Edition,
Feb. 2008
2 PCE-5B10-04A1E Startup Manual
Connectors and Jumpers
This table shows the function of each jumper and connector:
Connectors
Label Function
SHBA1~SHBD1
PICMG1.3 CPU board slot
PPCIE2~5 PCIe x 1 slot
PPCIE1
PCIe x 16 slot
PPCI1~PPCI4 32 Bit / 33 MHz PCI Bus slot
EATXPWR1
ATX2.0 24-pin Power Connector
EATX12V1 ATX 12V Auxiliary 8-pin Power Con-
nector
ATX12V1
ATX 12V 4-pin Power Connector
PWR3V1 3.3V Auxiliary Power Connector
PWR3V2
3.3V Auxiliary Power Connector
VOLT1 Alarm board / CMM Power Connector
FAN1~6
FAN Connector (Horizontal Type)
FAN7 FAN Connector (Vertical Type)
FANDEC1
FAN speed detector Connector
SMBUS1-3 System Management Bus
JFP1
Power and Reset button Connector
IPMB1 IPMB Connector
USB12
Two USB port pin header
USB34 Two USB port pin header
Jumpers
Label Function
PSON1
ATX / AT Mode Selection
EATXPWER1
Pin Name
1
3.3 V
2 3.3 V
3
GND
4 5 V
5
GND
6
5 V
7
GND
8 Power OK
9
5 V SBY
10
12 V
11
12 V
12 3.3 V
13
3.3 V
14 -12 V
15
GND
16 PSON#
17
GND
18 GND
19
GND
20 -5 V
21
-5 V
22 5 V
23
5 V
24 GND
ATX12V1
Pin Name
1
GND
2 GND
3
12 V
4 12 V
PCE-5B10-04A1E Startup Manual 3
FANDEC1
Pin Name
1
FANIO1
2 FANIO2
3
FANIO3
4 FANIO4
5
FANIO5
6
FANIO6
7
FANIO7
SMBUS1~SMBUS3
Pin Name
1
5 V
2 C-SMBBUS
3
C-SMBDAT
4 GND
IPMB1
Pin Name
1
IPMB_CLK
2 IPMB_DAT
3
GND
USB12
Pin Name
1
USBV0
2 USBV0
3
USBD0-
4 USBD1-
5
USBD0+
6
USBD1+
7
GND
8 GND
9
Null
10
GND
EATX12V1
Pin Name
1
GND
2 GND
3
GND
4 GND
5
12 V
6
12 V
7
12 V
8 12 V
PWR3V1 & PWR3V2
Pin Name
1
3.3V
2 3.3V
3 3.3V
4 GND
5
GND
6
GND
VOLT1
Pin Name
1
5 V SBY
2 GND
3
GND
4 -5 V
5
5 V
6
3.3 V
7
-12 V
8 12 V
FAN1~FAN7
Pin Name
1
GND
2 12 V
3
FANIO1~FANIO7
