PCE-5B06V(7B06V)-04A1E Startup Manual 1

PCE-5B06V-04A1E (PCE-7B06V-04A1E) Backplane: 6-slot BP for 2U Chassis,

1PICMIG 1.3, 1 PCIe, 4 32-bit PCI

PCE-5B06V-04A1E (PCE-7B06V-04A1E) Backplane:

6-slot BP for 2U Chassis, 1 PICMIG 1.3, 1 PCIe, 4

32-bit PCI

Startup Manual

Before you begin installing your card, please make sure

that the following materials have been shipped:

If any of these items are missing or damaged, contact your

distributor or sales representative immediately.

Standard Functions

• PICMIG 1.3 slots:

PCE-7B06V-04 supports PCE-7xxx CPU boards

PCE-5B06V-04 supports PCE-5xxx CPU boards

• PCIe slots:

PCE-7B06V-04 supports one PCIe p1-x8 slot

PCE-5B06V-04 supports one PCIe x16 slot

• 32-bit PCI:

Four 32-bit / 33 MHz PCI slot

• USB (2.0) support: Four Universal Serial Bus ports to

Backplane

Mechanical and Environment

• Dimensions: 80.01 x 325 mm

• Power supply voltage: +12 V, +5 V, -12 V, -5 V, +5 V

SBY, +3.3 V

• Power requirements: Refer to the CPU Board, add-on

Card & Peripherals

• Operating temperature: 0 ~ 60° C

• Weight: 0.211 kg (weight of board)

Packing listSpecifications

• One 2 Ports USB Cablep/n: 1700002204

• PCE-5B06V-04A1E (PCE-

7B06V-04A1E) Startup Manual

• M4*6*0.7 Round Screws (5 pcs)

p/n: 1939000410

• 2 years quality warranty card p/n: 2190000902

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

http://www.advantech.com/eplatform

For technical support and service, please visit our

support website at:

http://www.advantech.com/support

This manual is for the PCE-5B06V-04A1E (PCE-

7B06V-04A1E) series Rev. A1

Part No. 200K5B0621

Printed in China

2nd Edition

August 2012
