PCE-5B04-20A1E (PCE-7B05-20A1E) Startup Manual 1

Before you begin installing your card, please make sure that

the following items have been shipped:

2 Two Port USB Cable p/n: 1700002204

PCE-5B04-20A1E (PCE-7B05-20A1E) Startup Manual

M4*6*0.7 Round Screws (5 pcs) p/n: 1939000410

2 Year Quality Warranty Card p/n: 2190000902

If any of these items are missing or damaged, please con-

tact your distributor or sales representative immediately.

1.

2.

3.

4.

PCE-5B04-20A1E (PCE-7B05-20A1E) Backplane: 4(5)-

slot BP for 5-slot Chassis, 1 PICMIG 1.3, 1(2) PCIe, 2

64-bit 133-MHz PCI-X

Startup Manual

Standard Functions

PICMIG 1.3 slots:

PCE-7B05-20A1E supports PCE-7xxx CPU boards

PCE-5B04-20A1E supports PCE-5xxx CPU boards

PCIe slots:

PCE-7B05-20A1E supports two PCIe x 8 slots

PCE-5B04-20A1E supports one PCIe x 16 slot

64-bit PCI-X:

Two 64 Bit / 133 MHz PCI-X Slots

USB (2.0) support:

Four Universal Serial Bus ports to Backplane

Mechanical and Environment

Dimensions: 106.5 x 325 mm

2

Power supply voltage: +12 V, +5 V, -12 V, -5 V, +5 V SBY,

+3.3 V

Power requirements: Refer to the CPU Board, add-on

Card & Peripherals

Operating temperature: 0 ~ 60° C

•

•

•

•

•

•

•

•

Specications Packing List

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

http://www.advantech.com/epc

For technical support and service, please visit our

support website at:

http://service.advantech.com.tw/eservice/

This manual is for the PCE-5B04-20A1E (PCE-7B05-

20A1E) series

Part No. 200K5B0400

Printed in China

1st Edition

June 2008
