Pagina 1/5
MIC-3810 Startup Manual 1
Before you begin installing your IPC, please make sure that
the following items have been shipped:
1. 1 x MIC-3810-A1D1
2. 2 x Screws M2.5*6LR/S D
3. 1 x Screws M2.5x4.5L 1/4R/S D
4. 1 x Display card panel cover(U)
If any of the above items are missing or damaged, contact
your distributor or sales representative immediately.
Note: Acrobat Reader is required to view any PDF le.
Acrobat Reader can be downloaded at:
www.adobe.com/Products/acrobat/readstep2.
html (Acrobat is a trademark of Adobe)
MIC-3810
3U CompactPCI
®
Serial PCIe Carrier Board
Startup Manual
Standard Functions
• Backplane Interface: PCIe Gen3 x8
• PCIe Connector: PCIe x16, backwards compatible PCIe
x1, PCIe x4, PCIe x8
• Card Size: maximum dimensions of 176 x 68.9 mm (6.9”
x 2.7” inches).
• Power: +12V, +5V standby: Power consumption depend-
ing on plugged module, supports up to 80W
Mechnical and Environment
• Dimensions (W x H x D): 160.00 x 100.00 mm (6.30” x
3.95”)
• Non-operating Temperature: -40 ~ 85 °C (-40 ~ 185 °F)
• Operating Temperature (depending on module): -40 ~
70 °C (-40 ~ 158 °F)
• Operating Humidity: 95% @ 40 °C, non-condensing
• Non-operating Humidity: 95% @ 60 °C, non-condensing
• Vibration (5~500 Hz): 2.0 Grms
Packing List
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/epc
For technical support services, please visit our support
website at:
http://support.advantech.com
This manual is for the the MIC-3810-A1D1.
Part No. 2041381000
Printed in China
Edition 1
July 2022
Specications
2 MIC-3810 Startup Manual
P1PinDenition
Pin Number Net Name Pin Number Net Name Pin Number Net Name Pin Number Net Name
A1 +12V_HOT B1 +5V_STANDBY C1 GND D1 +12V_HOT
A2 GND B2 SMB_P1_CLK C2 SMB_P1_SDA D2 GND
A3 NC B3 NC C3 P1_GA0 D3 NC
A4 GND B4 NC C4 NC D4 GND
A5 PEG_P1_TX0P B5 PEG_P1_TX0N C5 GND D5 PEG_P1_RX0P
A6 GND B6 PEG_P1_TX2P C6 PEG_P1_TX2N D6 GND
Pin Number Net Name Pin Number Net Name Pin Number Net Name Pin Number Net Name
E1 +12V_HOT F1 GND G1 +12V_HOT H1 +12V_HOT
E2 NC F2 P1_PLTRST# G2 GND H2 P1_PLTRST#
E3 NC F3 P1_GA1 G3 NC H3 NC
E4 PCIE_P1_CLKP F4 PCIE_P1_CLKN G4 GND H4 NC
E5 PEG_P1_RX0N F5 GND G5 PEG_P1_TX1P H5 PEG_P1_TX1N
E6 PEG_P1_RX2P F6 PEG_P1_RX2N G6 GND H6 PEG_P1_TX3P
Pin Number Net Name Pin Number Net Name Pin Number Net Name Pin Number Net Name
I1 GND J1 +12V_HOT K1 +12V_HOT L1 GND
I2 P1_WAKE_OUT# J2 GND K2 P1_PCIE_EN# L2 NC
I3 P1_GA2 J3 NC K3 NC L3 P1_GA3
I4 NC J4 GND K4 NC L4 NC
I5 GND J5 PEG_P1_RX1P K5 PEG_P1_RX1N L5 GND
I6 PEG_P1_TX3N J6 GND K6 PEG_P1_RX3P L6 PEG_P1_RX3N
P2PinDenition
Pin Number Net Name Pin Number Net Name Pin Number Net Name Pin Number Net Name
A1 PEG_P2_TX4P B1 PEG_P2_TX4N C1 GND D1 PEG_P2_RX4P
A2 GND B2 PEG_P2_TX6P C2 PEG_P2_TX6N D2 GND
A3 NC B3 NC C3 GND D3 NC
A4 GND B4 NC C4 NC D4 GND
A5 NC B5 NC C5 GND D5 NC
A6 GND B6 NC C6 NC D6 GND
A7 NC B7 NC C7 GND D7 NC
A8 GND B8 NC C8 NC D8 GND
Pin Number Net Name Pin Number Net Name Pin Number Net Name Pin Number Net Name
E1 PEG_P2_RX4N F1 GND G1 PEG_P2_TX5P H1 PEG_P2_TX5N
E2 PEG_P2_RX6P F2 PEG_P2_RX6N G2 GND H2 PEG_P2_TX7P
E3 NC F3 GND G3 NC H3 NC
E4 NC F4 NC G4 GND H4 NC
E5 NC F5 GND G5 NC H5 NC
E6 NC F6 NC G6 GND H6 NC
E7 NC F7 GND G7 NC H7 NC
E8 NC F8 NC G8 GND H8 NC
PinDenition
MIC-3810 Startup Manual 3
Pin Number Net Name Pin Number Net Name Pin Number Net Name Pin Number Net Name
I5 GND J5 PEG_P1_RX1P K5 PEG_P1_RX1N L5 GND
I6 PEG_P1_TX3N J6 GND K6 PEG_P1_RX3P L6 PEG_P1_RX3N
I1 GND J1 PEG_P2_RX5P K1 PEG_P2_RX5N L1 GND
I2 PEG_P2_TX7N J2 GND K2 PEG_P2_RX7P L2 PEG_P2_RX7N
I3 GND J3 NC K3 NC L3 GND
I4 NC J4 GND K4 NC L4 NC
I5 GND J5 NC K5 NC L5 GND
I6 NC J6 GND K6 NC L6 NC
I7 GND J7 NC K7 NC L7 GND
I8 NC J8 GND K8 NC L8 NC
PCIEInterfacePinDenition
Pin Number Net Name Pin Number Net Name Pin Number Net Name Pin Number Net Name
A1 GF1_PRSNT1# A42 GND B1 +12V B42
PCIEX8_P2_
RX6N
A2 +12V A43
PCIEX8_P2_
TX6P
B2 +12V B43 GND
A3 +12V A44
PCIEX8_P2_
TX6N
B3 +12V B44 GND
A4 GND A45 GND B4 GND B45
PCIEX8_P2_
RX7P
A5 JTAG2 A46 GND B5 PCIE_SMBCLK B46
PCIEX8_P2_
RX7N
A6 JTAG3 A47
PCIEX8_P2_
TX7P
B6 PCIE_SMBDAT B47 GND
A7 NC A48
PCIEX8_P2_
TX7N
B7 GND B48 NC
A8 JTAG5 A49 GND B8 +3.3V B49 GND
A9 +3.3V A50 NC B9 JTAG1 B50 NC
A10 +3.3V A51 GND B10 .+V3.3_AUX B51 NC
A11 PCIE_PLTRST# A52 NC B11
P1_WAKE_
OUT#
B52 GND
A12 GND A53 NC B12 NC B53 GND
A13 CLK_PCIE_P A54 GND B13 GND B54 NC
A14 CLK_PCIE_N A55 GND B14
PCIEX8_P1_
RX0P
B55 NC
A15 GND A56 NC B15
PCIEX8_P1_
RX0N
B56 GND
A16 PCIEX8_P1_TX0P A57 NC B16 GND B57 GND
A17 PCIEX8_P1_TX0N A58 GND B17 NC B58 NC
A18 GND A59 GND B18 GND B59 NC
A19 NC A60 NC B19
PCIEX8_P1_
RX1P
B60 GND
A20 GND A61 NC B20
PCIEX8_P1_
RX1N
B61 GND
A21 PCIEX8_P1_TX1P A62 GND B21 GND B62 NC
PinDenition(Cont.)
