ITA-5831 Startup Manual 1

The ITA-5831 series of compact fanless systems are

powered by a 6th generation Intel® Core™ i processor and

fully compliant with the EN 50155 standards for railway and

industrial applications. These powerful computing platforms

can withstand 24/7 operation under harsh conditions.

Before card installation, ensure that the following items

have been shipped:

1. 1 x ITA-5831 series IPC

2. 1 x ITA-5831 accessory box

3. 1 x ITA-5831 warranty card

If any of the above items are missing or damaged, contact

your distributor or sales representative immediately.

Note 1: FordetailedITA-5831specications,refertothe

Advantech website http://www.advantech.com.

Note 2: Acrobat Reader is required to view any PDF

le.AcrobatReadercanbedownloadedfrom

http://get.adobe.com/reader/ (Acrobat is a trade-

mark of Adobe)

ITA-5831 Series of Compact Fanless Systems with

6th Generation Intel® Core™i Processor and

EN 50155 Certication for Railway Applications

Startup Manual

Standard Functions

•Chip and Chipset: Intel® Core™ i BGA1023 processor

with QM170, CPU frequency 2.8 GHz max.

•BIOS: AMISPI128MBash

•Memory: Onboard 8 GB/16 GB DDR4, 2133 MHz

•Display: Intel Integrated Graphics GT2

Up to 512 MB shared memory, supports Direct x11

•Display Mode:

- DVI: 1920x1200 @ 60 Hz

- VGA: 1920x1200 @ 60 Hz (optional)

•Storage: Supports 3 x 2.5” SSD (hot-pluggable, RAID

0,1,5,10), 1 x internal mSATA slot

•Expansion: 3 x Mini PCIe slots (2 with SIM slot)

SystemSpecications

•Ethernet: 3 x 10/100/1000M Ethernet, M12 x-coded,

8-pin, Female

•USB:

1 x USB 2.0, M12 A-coded, 4-pin, Female

2 x USB 3.0, Type A

•Display: 1 x DVI-I connector

•Serial Port:2xDB9withRS-232/422/485automaticow

control

•Digital I/O: 4 x DI and 4 x DO with 2kV isolation, DB9/

Female

•Audio: 1xAudioOut(supports2-ch4W4Ωspeaker),

1 x Line In, DB9/Female

Mechanical and Environmental

•Dimensions (W x H x D):

- 220 x 88 x 197.2 mm (8.66 x 3.46 x 7.76 in)

- 256 x 93.5 x 197.2 mm (10.0 x 3.68 x 7.76 in) with mount kit

•Input Voltage: Compliant with EN 50155/EN 50121-3-2

24V

DC

, 4.16A

48V

DC

, 3.18A

72V

DC

, 2.12A

110V

DC

, 1A

•Operating Temperature: -40 ~ 70 °C (-40 ~ 158 °F) with

wide-temperature SSD, EN50155 Tx level

•Safe Operating Temperature: 50 °C (122 °F) max.

•Storage Temperature: -40 ~ 85 °C (-40 ~ 185 °F)

•Weight: 4.5 kg (9.92 lb)

Specications Packing List

For more information about this or other Advantech

products, visit the Advantech website at

http://www.advantech.com

For technical support and customer service, visit the

Advantech support website at

http://support.advantech.com.tw

This manual is for the ITA-5831 series.

Part No. 2041583111

Printed in China

Edition 2

June 2021
