ITA-3650 Startup Manual 1

Before you begin installing your IPC, please make sure that

the following items have been shipped:

1. 1 x ITA-3650 series IPC

2. 1 x Accessary box

3. 2 x Mounting brackets

4. 4 x Bottom rubber pads

5. 1x Warranty card

If any of these items are missing or damaged, please con-

tact your distributor or sales representative immediately.

Note : Acrobat Reader is required to view any PDF

le.Acrobat Reader can be downloaded at:

www.adobe.com/Products/acrobat/readstep2.

html (Acrobat is a trademark of Adobe)

ITA-3650 Series Fanless Compact Embedded IPC with Intel 6th &

7th Generation Desktop Processor

Startup Manual

Standard Functions

•Chip and chipset: Intel 6th & 7th Generation Desktop

Processor with H110 or C236 PCH

•BIOS: AMI SPI 64 MB Flash

•Memory: On board 8GB DDR4, optional on board 16G

max to 32GB with SO-DIMM

•Display: Intel HD Graphics 630/610/530/510

•Dual display mode:

- Resolution of single display up to 3840 x 2160 @ 30H

- Resolution of dual display up to 1920 x 1080 @ 60Hz

•Storage: Supports 1 x M-Sata slot and 2 x 2.5” HDD/SSD

•Expansion slot: Supports 1 x Mini PCIe slot

SystemSpecications

•Ethernet: 2 or 6 x 10/100/100M Ethernet

•USB: 2 x USB 2.0, 4 x USB 3.0

•DISPLAY: 1 x VGA, 1 x HDMI

•Serial port: 2 serial ports, with RS-232/422/485; 4 serial

ports only RS-232(ITA-3650-00A1); 8 serial ports, with

RS-232/422/485(ITA-3650N-00A1)

•Digital I/O: 12 GPIs and 12 GPOs(ITA-3650N-00A1)

•Audio: 1 x speaker out (supports 2-ch 4w speaker), 1 x

line in

Mechnical and Environment

•Dimensions (W x H x D):

ITA-3650-00A1: 210 x 76 x 240 mm(8.27’’ x 2.99’’ x 9.45’’)

ITA-3650N-00A1: 210 x 118 x 240 mm(8.27’’ x 4.65’’ x

9.45’’)

•Voltage input: DC 9 ~ 36 V input

•Working temperature:

-25 ~ 60° C (-13 ~ 140° F)

•Weight:

ITA-3650-00A1: 4.03 kg

ITA-3650N-00A1: 4.65 kg

Specications

Packing List

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

http://www.advantech.com/epc

For technical support and service, please visit our

support website at:

http://support.advantech.com

This manual is for the ITA-3650 Series.

Part No. 2041365000

Print in China

1st Edition

July 2019
