AMAX-4870 Startup Manual 1
Before installation, check that the following items are
included in the shipment:
• 1 x AMAX-4870 EtherCAT junction
• 2xTerminalblocks(seeSpecicationsformoredetails)
• 1 x AMAX-4870 startup manual
If any of these items are missing or damaged, contact your
distributor or sales representative immediately.
For more detailed information about this product, download
the latest user manual from the Advantech website.
The conguration data of an EtherCAT SubDevice module
is stored in an EtherCAT SubDevice information (ESI) le.
Various EtherCAT communication settings can be dened
fromtheESIlesofconnectedSubDeviceunitsaswellthe
network connection information. ESI les are saved to the
conguration tool to facilitate network conguration. The
networkcongurationdatacanbedownloadedtotheEther-
CAT MainDevice unit for conguring EtherCAT networks.
TheAMAX-4870ESIlecanbedownloadedfromthe
Advantech website.
AMAX-4870
6-Port EtherCAT Junction SubDevice Module
Startup Manual
AMAX-4870isa6-portEtherCATjunctionSubDevicemodule
thatsupports exiblewiring congurationsinline, tree,and
star topologies, allowing EtherCAT systems to remain opera-
tional in the event of a machine error requiring a shutdown.
The AMAX-4870 module can also enhance debugging
and maintenance eciency for optimum performance.
Furthermore,AMAX-4870hasbeenveriedbytheEtherCAT
Conformance Test Tool and can support most third-party
MainDevice modules (TwinCAT, CODESYS, and Acontis).
General
• Protocol:EtherCAT
• Ports
In: 1 port
Out:5ports
• DataRate:100 Mbps max.
• PowerInput:10 ~ 30 V
DC
• I/OConnector
2x3-pin3.81-mmscrewterminalblock(power)
6xRJ-45(EtherCAT)
• Dimensions(WxDxH): 120 x 120 x 40 mm
(4.72x4.72x157in)
• PowerConsumption
24V:140mA(typical);190mA(max.)
• OperatingTemperature:-20~60°C(-4~140°F)
• StorageTemperature:-40~70°C(-40~158°F)
• StorageHumidity:5~95%RH(non-condensing)
1. DownloadtheAMAX-4870usermanualandESIle
from the Advantech website.
2. ImporttheESIletocreateanEtherCATnetwork
information(ENI)leusingeither
- Advantech Common Motion Utility
(withaPCI-1203EtherCATMainDevicecard)
-OtherEtherCATMainDevicesoftware
(suchasTwinCATorAcontis)
3. UsetheMainDeviceutilitytotestAMAX-4870.
PackingList
For more information about this or other Advantech
products, please visit our website at
http://www.advantech.com
For technical support and customer services, please
visit our support website at
http://support.advantech.com
This manual is for AMAX-4870.
Part No. 2041487001
Printed in China
Edition 2
April 2023
Specications
Overview
UserManual
EtherCATSubDeviceInformationFile
Installation
2 AMAX-4870 Startup Manual
Flickering Bootstrap
The device is booting
and has not yet entered
the Initialization state/the
device is in the Bootstrap
state/armwaredown-
load is in progress
ErrorIndicators
IndicatorState ErrorName Description
O No Error
The device is in work-
ing condition
Blinking
InvalidCongu-
ration
Generalconguration
error
Singleash Local Error
ASubDevicedevice
application has
changed the EtherCAT
state autonomously
due to a local error/
the error indicator bit
is set to 1 in the AL
Status register
Doubleash
Watchdog
Timeout
An application
watchdog timeout has
occurred
LinkIndicator(onRJ-45)
IndicatorState Link Activity Description
On Yes No Port open/connected
Flickering Port open/connectedYes Yes
O No N/A
Port closed/discon-
nected
FCCClassA
This equipment has been tested and found to comply with
thelimitsforaClassAdigitaldevice,pursuanttopart15of
the FCC Rules. These limits are designed to provide rea-
sonable protection against harmful interference when the
equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications.Operationof thisequipmentin residential
areas is likely to cause interference. In such cases, users
are required to correct the interference at their own expense.
CE
This product has passed the CE test for environmen-
tal specications when shielded cables are used for
external wiring. We recommend the use of shield-
ed cables. Advantech does provide shielded cables.
Contact your local supplier for ordering information.
AMAX-4870 features two power input terminals, an input
power range of 10 ~ 30 V
DC
, and power redundancy sup-
port. For modules connected to two power input sources,
if one source is inactive or interrupted, the other power
source can take over immediately. The AMAX-4870 junc-
tion module can operate with only a single power source.
PowerIndicators
IndicatorState SystemState Description
O Powero
The system is not on/
poweriso
On Power on
The system is on/power
is on
RunIndicators
IndicatorState
SubDevice
State
Condition
O Initialization
The device is in the
Initialization state
Blinking
Pre-Opera-
tional
The device is in the Pre-
Operationalstate
Singleash
SafeOpera-
tional
The device is in the Safe
Operationalstate
On Operational
The device is in the
Operationalstate
DeclarationofConformity
Power
LEDs(Cont.)
Dimensions
LEDs
