iMouse T50_QGS_EN_051518

LIMITED WARRANTY

Adesso provides a one year limited warranty for all of its products against defects in

material and workmanship.

During this period, Adesso will repair or replace any product which proves to be defective.

However, Adesso will not warranty any product which has been subject to improper freight

handling, shipping abuse, neglect, improper installation or unauthorized repair. The

warranty will not cover products installed with components not approved by Adesso and

products where the sealed assembly trace has been broken.

If you discover a defect, Adesso will, at its option, repair or replace the product at no charge

to you provided you return it during the warranty period with freight charges pre-paid to

Adesso. Before returning any product, you must obtain a Return Merchandise Authorization

number (RMA). This RMA # must be clearly marked on the outside of the package you are

returning for warranty service. Be certain to also include your name, shipping address (no

PO Boxes), telephone number, and a copy of the invoice showing proof of purchase in the

package.

SUPPORT

We have listed most of our FAQ’s (Frequently Asked Questions) at: http://www.ades-

so.com/faqs.asp. Please visit our FAQ Service & Support pages before you contact our

E-mail or Telephone Support.

Email Support:If our FAQ’s do not help you resolve your issues, please email

[email protected]

Telephone Support:

Toll Free: (800) 795-6788

9:00AM to 5:00PM PST Monday - Friday

4. Once you have followed the installation steps, go into your “system tray” by

clicking on the arrow located to the left of your Windows clock and click on the

Trackball Mouse Icon

5. Once you click on the Trackball Mouse Icon, it will bring up the driver menu

as shown below. Click on “Button Assignment” to change your mouse buttons.

6. Click on “Sensitivity” to change the speed of your mouse cursor as well as

adjust DPI settings, “Manage Macros” to assign macro keys for your mouse,

“Color Control” to change the color of the scroll wheel, and “Support” for prod-

uct support information.

1

1. Turn on your computer.

The iMouse T50 comes with a driver for customization which allows you

to customize your mouse to your preference. Change the DPI colors,

reassign mouse buttons, and assign macro keys all with this included

driver.

1. Flip the unit to its back on a flat surface and locate the hole where the trackball is

enclosed, then use a pen or a finger to appply pressure to “pop out” the trackball.

2. Use a microfiber cloth to wipe the trackball and the trackball compartment.

Return the trackball by putting it back to its compartment. Please make sure it

is placed securely and properly before returning to operate the device.

•When low on batteries, the Scroll Wheel LED light will flash RED repeatedly.

•To conserve battery power, please turn “” the device when it’s not in use.OFF

• To re-establish connection between the device and the receiver. Follow below

steps:

1. Insert the wireless USB receiver into a new USB port.

2. Turn off the device and reinsert fresh batteries.

3. Turn of the device and press the connect button within 1 feet of the wireless

receiver.

4. Your device should now be connected and ready to use.

QuickGuide

English

www.adesso.com

iMouse

™

T50

Wireless Programmable Ergonomic Trackball Mouse

Model: iMouse T50

INTRODUCTION

SPECIFICATIONS

REQUIREMENTS

ADVANCED DRIVER FEATURES

TIPS

REMOVING THE TRACKBALL

HARDWARE INSTALLATIONCONTENTS

Hand Orientation:

Tracking Method:

Connection:

DPI Resolution:

Working Range:

Battery:

Buttons:

Trackball Diameter:

Dimensions:

Weight:

• Operating System: Window

®

7 or above

•An available USB port for the usb wireless receiver

Ambidextrous

Optical Sensor

2.4 GHz Radio Frequency Wireless Technology

400-4,800 DPI Range

up to 30 feet (10 m)

2 AAA Batteries

7 buttons(Forward & Backward, Left & Right, Scroll

Wheel, DPI UP/Down) Customizable by driver.

2” (50.8 mm)

6.0” x 4.3” x 2.4” (154 x 109 x 61 mm)

0.53 lb. (240g)

AAA Batteries

AAA Batteries

iMouse

™

T50(2) AAA

Batteries

QuickGuide

English

www.adesso.com

iMouse

™

T50

Wireless Programmable Ergnomic Trackball Mouse

Model: iMouse T50

Quick GuideUSB Wireless

Receiver

DESCRIPTION

Forward

Backward

Trackball

Left

Click

Right

Click

Adjustable

Leg Stand

Scroll

Wheel

DPI Up

DPI

Down

Rubber Paddings

Rubber Paddings

Connect

Button

Trackball

Removal

Hole

Battery

Cover

On/Off

Switch

2. Remove the back battery cover of the unit and locate the wireless usb

receiver. Now insert it into your computer’s USB port and your operating

system will automatically detect and install the device.

3. Turn on your device with the ON/OFF switch. The device will automatically

pair with the inserted USB receiver.

Power ON

USB Wireless

Receiver

Meet one of the newest models of the Adesso Trackball product line, the Adesso

iMouse™ T50. This device is cable-free by utilizing the 2.4 GHz radio frequency

technology, offering a wireless range of up to 30 feet. It’s also fully programmable,

meaning every mouse button can be customized to your preferred function with its

programmable driver. With its 5 levels of DPI resolutions (400-4800), the optical

trackball provides superior accuracy and smooth motion, reducing hand movement

and space. This mouse trackball is also easy to maintain - just push trackball outward

from back, clean and push it back in place. Its ergonomically contoured large size

trackball and adjustable leg stands further completes its ergonomic advantages,

making your daily computing tasks more comfortable and stress-free.

1. Please Insert below URL link into your web browser to download the

iMouse T50 Driver:

https://www.adesso.com/download/iMouse_T50_driver.zip

2. When the driver has finished downloading, please locate the zipped

folder and unzip it to locate the setup.exe file.

3. Then execute the setup.exe to begin driver installation.Please follow

the installation wizard prompt to finish the installation process.
