Adder Link X2-Silver DA Handleiding
Adder
AV extender
Link X2-Silver DA
Bekijk gratis de handleiding van Adder Link X2-Silver DA (26 pagina’s), behorend tot de categorie AV extender. Deze gids werd als nuttig beoordeeld door 4 mensen en kreeg gemiddeld 4.3 sterren uit 2.5 reviews. Heb je een vraag over Adder Link X2-Silver DA of wil je andere gebruikers van dit product iets vragen? Stel een vraag
Pagina 1/26
1
SECT 1
Contents
Welcome
Introduction .................................................................................2
Supplied items - X2 Dual Access Silver .......................................3
Supplied items - X2 Dual Access Gold .......................................4
Optional items .............................................................................5
Installation and operation
Installation ...................................................................................6
Stage A - Configuration switch settings ................................6
LOCAL module switches .....................................................6
REMOTE module switches .................................................7
Stage B - Mounting a module – desk or rack ........................8
Installation Advice ..............................................................8
Stage C - Connections ............................................................. 9
Connections at the LOCAL module ...................................9
Connections at the REMOTE module .............................. 11
Operation ...................................................................................13
Power and activity indicators ............................................... 13
General use ...........................................................................13
User arbitration and keyboard indicators ......................13
Visible image shadows ..................................................... 13
Locking and unlocking the system ......................................14
Special configuration
Configuration ............................................................................15
What are hotkeys? ...........................................................15
Entering, using and exiting configuration mode ...........15
Password setting ...................................................................16
Password override .................................................................16
Hot plugging and mouse restoration ..................................17
Which restore setting do I use? ....................................... 17
Microsoft and Logitech -specific mouse settings ................17
Image controls - sharpness and brightness .........................18
Skew adjustment ..................................................................19
Miscellaneous settings .......................................................... 21
Further information
Troubleshooting ........................................................................22
Getting assistance ......................................................................22
Emissions and Immunity ............................................................24
Product specificaties
| Merk: | Adder |
| Categorie: | AV extender |
| Model: | Link X2-Silver DA |
