Rackmount.IT RM-CI-T14 Handleiding

Rackmount.IT Niet gecategoriseerd RM-CI-T14

Bekijk gratis de handleiding van Rackmount.IT RM-CI-T14 (1 pagina’s), behorend tot de categorie Niet gecategoriseerd. Deze gids werd als nuttig beoordeeld door 4 mensen en kreeg gemiddeld 4.9 sterren uit 2.5 reviews. Heb je een vraag over Rackmount.IT RM-CI-T14 of wil je andere gebruikers van dit product iets vragen? Stel een vraag

Download PDF

Pagina 1/1

Type

Product Line

Type

Supported Models

DIMENSIONS

COLOR

PRODUCT DIMENSIONS

PACKING DIMENSIONS

(height x width x depth)

PACKAGE CONTENTS

MOUNTING INSTRUCTIONS

Consider the environment,

recycle where applicable.

In case of problems please contact your

reseller or sales@rackmount.it.

EMEA Ofce

Nonnenveld 27

4811 HN Breda

The Netherlands

T +31 76 200 37 40

E sales@rackmount.it

WWW.RACKMOUNT.IT

US Ofce

9201 Metric Blvd - Unit A

Austin - TX 78758

United States

T +1 512 521 03 33

E sales-us@rackmount.it

Qty Description

CISRACK

RM-CI-T14

MERAKI MX68

MERAKI MX68CW

MERAKI MX68W

MERAKI MX75

Metallic Blue

80 x 520 x 270 mm

3.14 x 20.47 x 10.63 in

44 x 482 x 217 mm

1.73 x 18.98 x 8.54 in

1. Remove the 4 rubber feet from your Cisco appliance.

2. Remove the 2 bolts (situated on the front side of the appliance) from the bottom of the Cisco appliance.

3. Place your Cisco appliance backwards through the FRONT opening of the rack.

4. Turn over the rack with the Cisco appliance.

5. For MX68: Use the original bolts to x the Cisco appliance on the rack and turn it back over.

For MX75: Use the provided bolts to x the appliance on the rack and turn it back over.

Tip: use a table edge so the appliance is pinned down to the frame and the bolt holes line up.

6. Place the power supply on the rack and tie it down with the 2 zip ties.

7. Lead the low voltage power cable through the large square hole towards the front of the rack and

connect it to the power inlet.

8. Tie the excess length of the power cable down with the 3rd zip tie.

9. Place the light pipe through the opening of the rack. See picture above.

10. Place your CisRack in your 19 inch rack.

Please ensure proper ventilation according to the network appliance manufacturer guidelines.

1 CisRack + light pipe

3 Zip ties

1 Torx T8 key

2 Bolts for MX75

Revision 1 - 12-10-2021
