Rackmount.IT RM-CI-T12 Handleiding


Bekijk gratis de handleiding van Rackmount.IT RM-CI-T12 (1 pagina’s), behorend tot de categorie Niet gecategoriseerd. Deze gids werd als nuttig beoordeeld door 7 mensen en kreeg gemiddeld 5.0 sterren uit 4 reviews. Heb je een vraag over Rackmount.IT RM-CI-T12 of wil je andere gebruikers van dit product iets vragen? Stel een vraag

Pagina 1/1
Type
Product Line
Type
Supported Models
DIMENSIONS
COLOR
PRODUCT DIMENSIONS
PACKING DIMENSIONS
(height x width x depth)
MOUNTING INSTRUCTIONS
Consider the environment,
recycle where applicable.
In case of problems please contact your
reseller or sales@rackmount.it.
EMEA Ofce
Nonnenveld 27
4811 HN Breda
The Netherlands
T +31 76 200 37 40
E sales@rackmount.it
WWW.RACKMOUNT.IT
US Ofce
9201 Metric Blvd - Unit A
Austin - TX 78758
United States
T +1 512 521 03 33
E sales-us@rackmount.it
Qty Description
CISRACK
RM-CI-T12
MERAKI GO
1U
Metallic Blue
80 x 520 x 270 mm
3.14 x 20.47 x 10.63 in
44 x 482 x 217 mm
1.73 x 18.98 x 8.54 in
1. Remove the 4 rubber feet from your Cisco appliance.
2. Remove the 2 bolts (situated on the front side of the appliance) from the bottom of the Cisco appliance.
3. Place your Cisco appliance backwards through the FRONT opening of the rack.
4. Turn over the rack with the Cisco appliance.
5. Use the original bolts to xate the Cisco appliance on the rack and turn it back over.
Tip: use a table edge so the appliance is pinned down to the frame and the bolt holes line up.
6. Place the power supply on the rack and tie it down with the 2 zip ties.
7. Lead the low voltage power cable through the large square hole towards the front of the rack and
connect it to the power inlet.
8. Tie the excess length of the power cable down with the 3rd zip tie.
9. Place the light pipe through the opening of the rack. See picture above.
10. Place your Cisco in your 19 inch rack.
Please ensure proper ventilation according to the network appliance manufacturer guidelines.
1 CisRack + light pipe
3 Zip ties
1 Torx T6 key
Revision 1 - 30-06-2021


Product specificaties

Merk: Rackmount.IT
Categorie: Niet gecategoriseerd
Model: RM-CI-T12
Kleur van het product: Blauw
Breedte: 482 mm
Diepte: 217 mm
Hoogte: 44 mm
Breedte verpakking: 520 mm
Diepte verpakking: 270 mm
Hoogte verpakking: 80 mm
Soort: Montagebeugel
Montage gereedschap: Ja
Certificering: Meraki Go GX20
Snelle installatiehandleiding: Ja
Maat: 19 "
Compatibiliteit: Meraki Go GX20
Rackcapaciteit: 1U
Code geharmoniseerd systeem (HS): 85389099

Heb je hulp nodig?

Als je hulp nodig hebt met Rackmount.IT RM-CI-T12 stel dan hieronder een vraag en andere gebruikers zullen je antwoorden
