- 1 -

Product names listed herein are trademarks of AS America, Inc.

© AS America, Inc. 2016

Thank you for selecting American Standard...

the benchmark of fine quality for over 100 years.

To ensure that your installation proceeds smoothly-please

read these instructions carefully before you begin.

RECOMMENDED TOOLS

M965746 (4/16)

ROUGHING-IN DIMENSIONS

ESTATE

®

TUB AND SHOWER

INSTALLATION

INSTRUCTIONS

T722.500

T722.501

T722.502

T722.507

T722.508

Plumbers’ Putty

or Caulking

Adjustable WrenchChannel Locks

Phillips Screwdriver

Certied to comply with ANSI A112.18.1M

• To assure proper positioning in relation to wall.

Note roughing-in dimensions.

Teon Tape

Flat Blade Screwdriver

FINISHED WALL

4"

TOP OF TUB RIM

BOTTOM OF TUB

74" (1879 mm)

FOR HEAD

CLEARANCE

3-3/4"

(97 mm)

2" TO 3"

(51 TO 76 mm)

18" (457 mm)

OPTIONAL

6-5/8"

(179 mm)

7-5/8"

(207 mm)

1/2" NPT

1/2" COPPER

FOR SLIP-ON

SPOUT

8"

(198 mm)

1-1/2"

4-11/16"

(121 mm)

7-3/8"

(187 mm)

9-1/2"

(223 mm)

OPTIONAL TO FINISHED

FLOOR USUALLY

BETWEEN 65'' AND 78"

(1651 AND 1981 mm)

"SEE ILLUSTRATION "

THREADED INLETS (STOPS)

INLETS

1/2" NPT

5-7/8"

(149 mm)

5-7/8"

(149 mm)

5-7/8"

(149 mm)

INLETS 1/2" NPT

OUTLETS

1/2" NPT

OUTLETS

1/2" NPT

3-3/8"

(86 mm)

3-3/8"

(86 mm)

THREADED INLETS

SHR. 1/2" NOM.

COPPER SWEAT

TUB 1/2" NOM.

COPPER SWEAT

4-1/16" (103 mm)

INLETS

4-1/16"

(103 mm)

4-1/16"

(103 mm)

INLETS

1/2" NOM.

COPPER

SWEAT

SHR. 1/2" NOM.

COPPER SWEAT

TUB 1/2" NOM.

COPPER SWEAT

2"

SWEAT

INLETS

SWEAT

INLETS (STOPS)

INLETS

1/2" NOM.

COPPER

SWEAT

7"

(160 mm)

2-3/4"

(83 mm)
